MACHINEVACUUM FORMINGVFB
MACHINE
VACUUM FORMING
VFB
The VFB Vacuum Forming machine is used to form parts using a mold. The VFB was developed to work with sheet or coil materials made of PET, PS, PVC, ABS, EVA, among others (upon consultation).
VFB40x60
Technical Specification: Useful molding area: 400 x 600 mm Maximum molding height: 180 mm Dimensions: 1700 x 800 x 1550 mm Weight: 300 kg Voltage: 220 V single-phase or three-phase Consumption: 6.0 kWh (approximate)
Button
VFB 50x90
Technical Specification: Useful molding area: 500 x 900 mm Maximum molding height: 180 mm Dimensions: 1900 x 1100 x 1550 mm Weight: 350 kg Voltage: 220 V single-phase or three-phase Consumption: 8.0 kWh (approximate)
Button
VFB60x120
Technical Specification: Useful molding area: 600 x 1200 mm Maximum molding height: 180 mm Dimensions: 2100 x 1400 x 1550 mm Weight: 400 kg Voltage: 220 V single-phase or three-phase Consumption: 10.0 kWh (approximate)
Button
VFB40x60
Technical Specification: Useful molding area: 400 x 600 mm Maximum molding height: 180 mm Dimensions: 1700 x 800 x 1550 mm Weight: 300 kg Voltage: 220 V single-phase or three-phase Consumption: 6.0 kWh (approximate)
Button
VFB 50x90
Technical Specification: Useful molding area: 500 x 900 mm Maximum molding height: 180 mm Dimensions: 1900 x 1100 x 1550 mm Weight: 350 kg Voltage: 220 V single-phase or three-phase Consumption: 8.0 kWh (approximate)
Button
VFB60x120
Technical Specification: Useful molding area: 600 x 1200 mm Maximum molding height: 180 mm Dimensions: 2100 x 1400 x 1550 mm Weight: 400 kg Voltage: 220 V single-phase or three-phase Consumption: 10.0 kWh (approximate)
